Automatic tonometer AND UA-1200AC

Distinctive features:

Intelligent control system Intellitronics, thanks to which automatic AND arm pressure monitors independently determine the required level of cuff inflation in accordance with the user's pressure characteristics.

This makes the measurement process fast, accurate and painless.

The texts on the device are written in Russian.

Indicator of the correct position of the cuff.

Movement indicator during measurements.

?? Possibility of self-setting of the level of air pumping into the cuff, which allows avoiding repeated injection of air into the cuff and shortening the measurement time.

Memory function for 90 measurements and calculation of the average pressure value to track the dynamics of changes in pressure level.

Arrhythmia indicator (function to detect irregular heartbeat) to prevent incorrect readings during measurement.

Information in the form of a special character is displayed.

Re-measurement is required.

The WHO (World Health Organization) color bar is a graphical indicator that will help you instantly assess a user's blood pressure in exact accordance with the classification of the World Health Organization.

If you get into the red" sector, you must urgently consult a doctor.

The standard cuff of the new generation Opti Cuff for arms with a shoulder circumference of 23 to 37 cm. The AND UA-1200 tonometer allows people of any body size to use the device.

The cuff, made of soft hypoallergenic material, is easily and tightly attached to the arm, and thanks to the increased volume of the chamber, measurements are carried out faster and more comfortably.

The main unit of the AND UA-1200 blood pressure monitor in the case is guaranteed for 10 years.

The package includes a case for storage and transportation and an AND TB-233C AC adapter.

The AND UA-1200 tonometer operates on 4 AA batteries or a power adapter.

Technical

Specifications:

Device Name: Digital Blood Pressure and Heart Rate Meter

Model: AND UA-1200

Measurement Technology: Intellitronics

Measurement method: oscillometric

Screen: liquid crystal

Pressure measurement range: 20 to 280 mm Hg

Pulse rate measurement range: from 40 to 200 bpm.

Limiting error of pressure measurement: ± 3 mm Hg

Limit error in measuring heart rate: less than 5% of readings

Cuff included: Standard AND OptiCuff cuff for arms with a circumference of 23 - 37 cm.

Arrhythmia indicator: Yes

High pressure indicator: Yes

Average calculation: Yes

Indicator of correct hand position: Yes

Movement indicator during measurements: Yes

Self-setting of the cuff inflation level: Yes

Electronic unit weight (without batteries): 265 gr.

Dimensions of the electronic unit: 140 X 60 X 105

Memory: Yes, 90 measurements

Air injection: automatic

Air release: automatic

Operating conditions: air temperature from +10? C to +40? C at a relative humidity of no more than 85%

Storage conditions: air temperature from -10? C to +60? C at relative humidity not more than 95%

Power supply: 4 AA cells (penlight batteries) or from the mains adapter

Adapter included: Yes, AND TB-233C

Warranty for the main unit: 10 years, for individual components: adapter and cuff - 1 year

Equipment

Tonometer, cuff, connector, power adapter, connecting tube, case, 4 AA batteries, instructions

Specifications

Arrhythmia indicator

Yes

Tonometer type

Auto

Tonometer memory

Saving the results of previous measurements

Cuff position

On the shoulder

Manufacturer country

China

Dimensions, mm

140 x 60 x 110

Item weight, g

500

Type of food

From 220V mains and batteries

Accuracy

± 3 mm.

rt.

Art.

(pressure), ± 5% (pulse)

Large cuff

Yes

Expiration date in days

3650

Brand name

AND

A type

Tonometer

Package weight, g

680

Measuring range

:

20 - 280 mm Hg

(pressure), 40 - 200 beats per minute (pulse)

"
